Quick answer: Buy a wiper as a matched system: a sealed marine wiper motor with the right shaft length for your windshield thickness, the right sweep angle for your glass, and an arm and blade sized so the blade clears the frame at both ends of the sweep. Choose a standard arm for small screens and a pantograph (parallel) arm for tall or wide windshields, and use stainless steel blades and arms that won't rust in salt air.

A wiper you can count on matters most when the weather turns: rain squalls, heavy spray in a head sea, or salt film at sunset when the glare makes it hard to see crab pots and channel markers. Car wipers are not built for this. Marine wipers use sealed motors, stainless arms and blades, and hardware made to go through a fiberglass or acrylic windshield and survive salt. This guide explains how to size each part so the whole system works together.

Step 1: Measure your windshield

Before buying anything, take three measurements:

Thickness where the motor will mount. This decides the motor shaft length. Measure the windshield or console panel plus any mounting spacer.
Height of the glass from the motor shaft up to the top of the frame. This decides arm length.
Width available on each side of the shaft. This decides how wide a sweep you can use without hitting the frame.

Step 2: Choose the motor shaft length

Marine wiper motors come with different shaft lengths so they fit different mounting thicknesses. Too short and the arm won't seat on the splines. Too long and the arm sits far off the glass.

Shaft length	Typical use
1.5 in	Thin acrylic or glass windshields, small runabouts
2.5 in	The most common size for fiberglass and framed windshields
3.5 in	Thick panels, spacer blocks, hardtop and enclosure installs

Always check the motor's installation sheet against your measured thickness.

Step 3: Pick the sweep angle and motor strength

Motors are sold by sweep angle, commonly 80 or 110 degrees. A wider sweep clears more glass but needs more side clearance. A heavy-duty or two-speed motor handles longer blades and heavy spray better than a light-duty unit. If you run offshore or have long blades, buy a heavy-duty motor. Sealed or waterproof motors last much longer when mounted where spray reaches them.

Step 4: Standard arm or pantograph arm?

Standard arm: one pivot. The blade swings in an arc and tilts as it moves. Fine for small and short windshields.
Pantograph (parallel) arm: a second linkage keeps the blade vertical through the whole sweep, so it clears a larger rectangular area. The better choice for tall, wide or flat windshields on center consoles and cruisers.

Arms are adjustable within a length range. Choose a range that covers your measured height.

Step 5: Size the blade

Blade length should cover most of the glass height without hitting the frame at the top or the bottom of its travel. Stainless steel blades with replaceable rubber hold up far better than painted steel. Replace the rubber at least once a season. Salt and UV harden it fast, and a hard blade smears instead of clearing.

Step 6: Install and wire it right

Seal the shaft hole with the supplied gasket and a marine sealant so water can't get into the console.
Use a marine wiper switch or an intermittent controller, and protect the circuit with a properly sized fuse or breaker (see our fuse and breaker guide).
Set the park position so the blade rests along the bottom or side of the glass, out of your line of sight.
Rinse the blade with fresh water after salty runs.

Common wiper mistakes to avoid

Buying the arm and blade before the motor. The motor's shaft length and sweep angle decide everything else. Start there.
Ignoring the park position. If the blade parks in the middle of your view, you will look through it all day. Set the park spot before tightening the arm.
Too long a blade for the arm. An oversized blade lifts off curved glass at the ends and chatters. Stay inside the arm maker's recommended blade range.
Skipping the gasket and sealant. A leaking shaft hole lets water drip onto console wiring and electronics behind the windshield.
Running a dry blade on salty glass. Rinse or spray the glass first. Dragging a blade over dried salt scratches acrylic and wears the rubber fast.

If your windshield is acrylic rather than glass, clean it only with products made for marine acrylic and replace blades more often. Acrylic scratches far more easily than tempered glass.

Our picks

All in stock at Boat Supplies Direct.

Frequently Asked Questions

Can I use car wipers on a boat?

No. Marine wipers use sealed motors, stainless arms and blades, and through-panel mounting made for spray and salt. Car parts corrode quickly and do not fit a boat windshield.

What shaft length wiper motor do I need?

Measure the thickness of the windshield or panel where the motor mounts, including any spacer. Common shaft lengths are 1.5, 2.5 and 3.5 inches. Choose the one that matches your thickness per the installation sheet.

What is a pantograph wiper arm?

A parallel linkage arm that keeps the blade vertical as it sweeps, clearing a larger rectangular area. It is the better choice for tall or wide windshields.

What size wiper blade do I need for my boat?

Pick a blade that covers most of the glass height without hitting the frame at either end of the sweep, and pair it with an arm whose adjustable range fits your windshield.

Why does my boat wiper smear instead of clear?

The rubber is usually hardened by sun and salt. Replace the blade or rubber insert, clean the glass, and check that the arm has enough spring pressure.

Do I need a two-speed wiper motor?

It is worth it if you run in heavy spray or rain often. A slower speed handles drizzle and a faster speed keeps up with spray in a chop.

This guide is general information. Follow the motor manufacturer's installation instructions and match all components to your windshield before drilling.
