Marine Toilet Buying Guide: Manual vs Electric, Fresh vs Raw Water Flush
Quick answer: Choose a manual head if you want the simplest, most reliable toilet with zero power draw, and an electric head if comfort and push-button flushing matter more. Pick freshwater flush for the least odor or raw-water flush to save your water tank. Then match bowl size (compact around 14 inches or household around 17 inches) to the space, and plan 1-1/2 inch sanitation hose to your holding tank.
A marine toilet, or head, is one of the most used and least loved systems on a boat. Get it right and nobody thinks about it. Get it wrong and you live with odors, clogs and awkward repairs. Unlike a household toilet, a marine head has to pump water in and waste out, often below the waterline, and send it to a holding tank or approved treatment device. This guide covers flush type, water source, bowl size, plumbing and the rules you need to follow.
Step 1: Manual or electric
| Type | Power | Pros | Best for |
|---|---|---|---|
| Manual | None | Simple, cheap, easy to rebuild, works with dead batteries | Small boats, sailboats, backup heads |
| Electric, raw-water intake | 12V or 24V | Push-button flush, does not use tank water | Cruisers with a good battery bank |
| Electric, freshwater flush | 12V or 24V plus pressure water | Cleanest bowl, least odor, quietest options | Larger boats with good water capacity |
| Electric macerating | 12V or 24V | Grinds waste, allows smaller discharge hose and longer runs | Heads far from the holding tank |
Electric heads draw significant current while flushing. Check the amp rating and make sure your wiring and battery bank can support it. Many owners with an electric head keep the ability to pump manually, or carry a manual head rebuild kit as backup.
Step 2: Freshwater flush or raw-water flush
- Raw-water flush pulls seawater through a thru-hull. It saves your freshwater tank, but marine organisms in the intake line die and decay, which is the classic source of the "rotten egg" head smell.
- Freshwater flush uses your pressurized water system, often through a solenoid valve. It nearly eliminates intake odor but uses tank water, so it suits boats with generous water capacity or a watermaker.
- Some heads can be converted between the two with a conversion kit.
Step 3: Choose bowl size and confirm fit
Compact bowls (around 14 inches) save space in small heads. Household or "regular" bowls (around 17 inches) are more comfortable, especially for adults. Measure floor space, height to the seat, and clearance for the pump handle or motor. If you are replacing a head, match the bolt pattern and hose port positions where you can to avoid re-plumbing.
Step 4: Plumb it to the holding tank
- Discharge hose: most heads use 1-1/2 inch sanitation hose to the holding tank. Use odor-resistant, smooth-bore sanitation hose only.
- Intake hose: typically 3/4 inch from a dedicated seacock for raw-water heads.
- Vented loops: if the bowl rim is near or below the waterline, install vented loops on the intake and discharge lines to prevent siphoning, which can flood and sink a boat.
- Short, downhill runs where possible, with no low spots for waste to sit.
Our marine hose and clamp guide covers sanitation hose and clamps, and the thru-hull and seacock guide covers the intake fitting.
Step 5: Follow the discharge rules
Any boat with an installed toilet must have a Coast Guard certified Marine Sanitation Device (MSD). For most recreational boats that means a holding tank (Type III), with pump-out at a dock or legal offshore discharge beyond 3 nautical miles. In No Discharge Zones, no sewage may go overboard, and any overboard valve must be secured closed.
Step 6: Keep it working
- Use only marine or quick-dissolve toilet paper, and nothing else.
- Flush enough water to clear the discharge hose completely, not just the bowl.
- Rebuild manual pumps every few seasons, before joker valves and seals fail.
- Use a holding tank treatment to control odor.
Common marine toilet mistakes
- No vented loop on a head installed below the waterline.
- Using water hose instead of sanitation hose, which permeates odor within a season.
- Under-flushing, leaving waste sitting in the discharge line.
- Undersized wiring to an electric head, causing weak flushes and burned motors.
Our picks for marine toilets
All in stock at Boat Supplies Direct.
Manual heads
Jabsco Manual Toilet, Compact Bowl and the Regular Bowl version are the go-to manual heads, and the Raritan PH Superflush is a robust alternative.
Electric heads
Johnson Pump Electric Compact Macerator 12V, the household-style Raritan Sea Era QC 12V, or the Jabsco 17 in Deluxe Flush Freshwater Electric.
Premium freshwater flush
Raritan Marine Elegance Freshwater with Smart Toilet Control for a quiet, household-like experience.
Conversions and plumbing
Jabsco 12V Electric Conversion Kit for Jabsco manual heads, the Jabsco 1-1/2 in Vented Loop, and Trident 1-1/2 in Premium Sanitation Hose.
Odor control
Raritan K.O. Bio-Active Treatment.
Buying parts often? Get Dock Pass.
Free shipping on every order, 5% off eligible products and 60-day returns for $49 a year. See how Dock Pass works.
Frequently Asked Questions
Should I get a manual or electric marine toilet?
Manual heads are cheaper, simpler and need no power. Electric heads are more comfortable and convenient but draw battery power, so many owners keep a manual backup option.
What is the difference between freshwater and raw-water flush?
Raw-water heads flush with seawater and save tank water but can develop intake odor. Freshwater heads use your tank and pressure pump for a cleaner, odor-free bowl.
Why does my boat toilet smell like rotten eggs?
Usually marine organisms dying in the raw-water intake line, or old sanitation hose that has permeated. Converting to freshwater flush or replacing hose usually fixes it.
Do I need a vented loop on my marine toilet?
Yes if the bowl rim is near or below the waterline at any angle of heel. Vented loops prevent seawater from siphoning in and flooding the boat.
What size hose does a marine toilet use?
Most use 1-1/2 inch sanitation hose for discharge and 3/4 inch hose for the raw-water intake. Macerating heads may use a smaller discharge.
Can I convert a manual head to electric?
Many popular manual heads, including Jabsco's manual models, have electric conversion kits. Check compatibility with your exact model first.
This guide is general information. Follow US Coast Guard Marine Sanitation Device rules, EPA and state No Discharge Zone regulations, your toilet manufacturer's instructions and ABYC standards, and use a qualified marine technician for plumbing and electrical work.
